support 4 channels 720P IPCAMs input, and 1 channel synchronous playback - See more at: http://www.escamera.com/nvr-series/es-nvr9004hv51.html#sthash.vcsmCczk.dpuf
| SOC | Hi3015 |
| Video Compression | H.264 |
| Frequency | 50/60Hz |
| IP video input | 4-ch 720P/D1/VGA |
| Performance | 100fps 720P recording and 1-ch 720P synchronous playback |
| HDMI output | NO |
| YPbPr output | NO |
| VGA output | 1280*1024/800*600 |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω) |
| Recording resolution | CIF/720P/D1/VGA |
| Network resolution | CIF/720P/D1/VGA |
| Record mode | Time/Alarm/Motion |
| Motion detect | Support |
| CMS | windows,imac |
| IE | Windows |
| Mobile OS | Windows mobile, iphone, android, symbian, blackberry |
| Backup Mode | Flash drive/ USB HDD/ USB CD&DVD-RW / Network download |
| Network protocol | DHCP,DDNS,UPNP,SMTP,FAB-D,FAB-B |
| Audio input | 1-ch |
| Audio output | 1-ch |
| Alarm input | 4-ch |
| Alarm output | 1-ch |
| Hard disk | 1*2000G |
| Mouse | Support |
| Remoter | Support |
| Speed dome | Support |
| Keyboard control | Support |
| DVD-RW | Optional |
| USB Interface | 2*USB2.0 |
| Network Interface | 100M RJ45 |
| Dimensions | 250(W)* 45(D)*230(H)mm |
| Power Supply | 12VDC |
| Consumption | <12W |
